DETAILS

• Piattaforma

  Moterra Neo

• Nome Modello

  Moterra Neo Carbon 1 C25152U

• Codice Modello

  C25152U

KIT TELAIO

• Telaio

  Moterra Carbon Front Triangle, SmartForm C1 Alloy Swingarm, 150mm travel, Proportional Response Tuned Suspension, removable downtube battery, alloy skid plate, 55mm chainline, internal cable routing, 148x12mm thru-axle, UDH hanger, post mount brake, 1.5” – 1.8” tapered headtube, 18mm two-bolt kickstand mount

• Forcella

  RockShox Lyrik Select+, 150mm, DebonAir, 15x110mm thru-axle, tapered steered, 44mm offset

• Serie sterzo

  Acros integrated sealed bearing, tapered

• Rear Shock

  RockShox Deluxe Select+, DebonAir, 2-Pos mode adjust, adjustable rebound

E-SYSTEM

• Motore

  Bosch Performance Line CX 250W

• Batteria

  Bosch PowerTube, 750Wh

• Carica batteria

  Bosch 4A

• Display

  Bosch Kiox 300 w/ LED remote

• Certifications

  UL2849

TRASMISSIONE

• Cambio

  Shimano XTR

• Leve cambio

  Shimano XT, 12-speed

• Catena

  Shimano XT, 12-speed

• Guarnitura

  FSA Bosch E-bike w/ 55mm chainline, 160mm, 34T

• Pacco pignoni

  Shimano XT, 10-51, 12-speed

FRENI

• Freni

  Shimano XT 8120 4-piston hydraulic disc, 203/203mm RT76 rotors

• Leve Freno

  Shimano XT hydraulic disc

RUOTE

• Cerchi

  WTB KOM Trail i30 TCS, 32h, tubeless ready

• Raggi

  DT Swiss Champion

• Dimensioni pneumatico

  2.6

• Dimensione Ruote

  29

• Mozzi

  (F) Formula 15x110mm thru-axle / (R) DT Swiss, 12x148mm thru-axle

• Pneumatici

  (F) Maxxis Minion DHF, 29x2.6", EXO, tubeless ready / (R) Maxxis Rekon, 29x2.6" (27.5x2.6" - size Small), EXO, tubeless ready

• Front Tire

  Maxxis Minion DHF, 29x2.6", EXO, tubeless ready

• Rear Tire

  Maxxis Rekon, 29x2.6" (27.5x2.6" - size Small), EXO, tubeless ready

COMPONENTI

• Manubrio

  HollowGram SAVE riser bar, Carbon, 35mm clamp, 30mm rise, 8° sweep, 5° rise, 780mm

• Attacco Manubrio

  Cannondale 2, 6061 Alloy, 35mm, 0°

• Impugnatura

  Fabric FunGuy

• Sella

  Fabric Scoop Shallow Elite, cro-mo rails

• Reggisella

  Cannondale DownLow Dropper, internal routing, 31.6, 125mm (S), 150mm (M), 170mm (L-XL)
